The Animal Welfare Initiative is the result of an alliance between agriculture, the meat industry and the food retail sector. The aim of the initiative is to make animal welfare an even stronger basis for action in the future and at the same time to anchor it firmly and on a broad basis in agricultural production, in the meat industry and in food retailing.
Our contribution to this initiative is the provision of products for the improvement of animal welfare in pig farming.
This includes
The pellet slide is operated via a lever. The dosing quantity can be regulated using an adjusting screw.
Filling can be carried out conveniently with a hand shovel.
Opening: 170 x 120 mm
Capacity: approx. 7 litres
Collecting tray: 220 x 125 x 25 m
For automatic feeding of pellets etc., the top is changed and a connection for the downpipe is inserted.
| Premium features: | Consisting of: |
|---|---|
| Sturdy design in stainless steel | Shell plate |
| Eating height adjustable without tools from 25 - 100 mm | Back plate |
| Suitable for wood or nibble sticks up to 60 x 60 mm | Adjustable inner slider |
| Support angle |
| Standard features: | Consisting of: |
|---|---|
| Sturdy design in stainless steel | Shell plate |
| Eating height adjustable without tools from 30 - 100 mm | Adjustable support angle |
| Suitable for wood or nibble sticks up to 60 x 60 mm |
With finely adjustable dosing quantity. Filling material e.g. straw pellets. Existing teething stick holders can be extended.
| Features: |
|---|
| U-slider for slot adjustmen |
| Collecting tray with trough 230 x 140 mm |
| With hopper (optional) |
| Dimensions: 85 x 75 x 500 mm |
To satisfy the pigs' urge to dig, the Krebeck straw dispenser gradually dispenses the straw through the rotating pendulum turntable. The economical dispensing into the collection tray enables the desired interactive activity, where all the material can be picked up. The dispensing gap can be infinitely adjusted using the height adjustment.
| Features: | Consisting of: |
|---|---|
| Sturdy design | KG T-piece and guide tube |
| Can be filled by hand | Pendulum turntable with driver |
| Filling via tube chain conveyor possible | Lever for slot gap adjustment |
| Good control over the material | Retaining plates for wall mounting |
| Injury-free fastening | Sheet metal clamps for pipe fastening |
| Cleaning with high-pressure cleaner possible | Collecting tray V2A 250 x 206 x 20 with support bracket |
Straw and other roughage can be reached from all sides by several pigs at the same time through the many openings in the straw trough, thus promoting the health of the pigs in line with the Animal Welfare Initiative.
| Features: |
|---|
| Material: stainless steel |
| Dimensions: 300/260 x 470 mm |
| Proven design since 2015 |
| Variable mounting possible, holes suitable for 1" pipes |
| Accessible from three sides |
| Slotted slide option |
Two rotating stars on the feeding plate allow straw to be dispensed to up to three pigs at the same time. The infinitely variable height adjustment of the dosing gap allows the amount of straw to be dispensed in a controlled manner. This allows the animals to fulfil their urge to forage in line with the animal welfare initiative.
| Features: | Consisting of: |
|---|---|
| Sturdy design | KG pipe (160 x 1000 mm) |
| Can be filled by hand | 5-sided feeding plate (325 x 400 mm) |
| Mounting on the partition wall | 2 rotary stars 5-piece |
| Filling by hand or via tube chain conveyor | Dimensions: 1080 x 325 mm (height x width) |
| Easy cleaning |
![[Translate to English:] Abbildung zeigt Strohautomat an der Trennwand](/fileadmin/_processed_/c/0/csm_strohautomat01_ab63b7fca0.jpg "[Translate to English:] Abbildung zeigt Strohautomat an der Trennwand")
![[Translate to English:] Abbildung zeigt: - Fressplatte für 3 Tiere mit Drehsternen - Befestigung an der Trennwand](/fileadmin/_processed_/1/c/csm_strohautomat02_6e61798313.jpg "[Translate to English:] Abbildung zeigt: - Fressplatte für 3 Tiere mit Drehsternen - Befestigung an der Trennwand")
![[Translate to English:] Abbildung zeigt Strohautomat in der Trennwand](/fileadmin/_processed_/9/3/csm_strohautomat03_80e88f42d2.jpg "[Translate to English:] Abbildung zeigt Strohautomat in der Trennwand")
Two rotating stars on the feeding plate allow straw to be dispensed to up to six pigs simultaneously. The infinitely variable height adjustment of the dosing gap allows the amount of straw to be dispensed in a controlled manner.
This allows the animals to fulfil their urge to forage in line with the animal welfare initiative.
| Features: | Consisting of: |
|---|---|
| Sturdy design | KG pipe (200 x 1000 mm) |
| Variable mounting possible: | 8-sided feeding plate (400 x 400 mm) |
| Freestanding or in partition wall | 2 rotary stars 5-piece |
| Filling by hand or via tube chain conveyor | 2 U-pillars for partition wall |
| Easy cleaning | Dimensions: 1080 x 403 mm (height x width) |
Shown here in the existing partition walls. Loading by hand.
| Features: |
|---|
| Variable feeding by hand or via pipe conveyor possible |
| Dosing takes place via a swivelling plate on the feed table |
| The amount of straw can be regulated via a lever |
| The feed opening has a diameter of Ø 200 mm |
| The stirring unit is driven by a rotary pendulum disc |
| Dimensions: 400 x 400 x 1200 mm |
Free in the bay.
Feeding by hand
Against clogging
Provides a stable scouring option with a rough surface. Can be mounted variably!
Can be extended to form an emergency bay.
Maintenance-free.
The pig presses the nipple, but the water runs into the bowl. The animal can then drink from this - just like in nature. Existing drinking troughs can be converted. The flat bowls are easy to clean! Drinking bowl also suitable for other makes.
